SC37: Signal Converter

- Programmable DC voltage or DC current input

- Isolated input to output

- Compact DIN rail mount enclosure

- High accuracy

- Low cost

- Easy to install

Specifications

Analog Input

Number of channel:

1 Channel

Input type:

Voltage, Current

Input range:

Voltage (10 mVDC to 100 VDC)

Current (100 uADC to 100 mADC)

Input impedance:

Current (Max 20 Ω)

Analog Output

Number of channel:

1 Channel

Output type:

Current (2 Wire)

Output range:

4 to 20 mA

Loop powered:

12 to 35 VDC

Accuracy:

< ± 0.2 % of span

Linearity:

< ± 0.2 % of span

Ambient drift:

< ± 0.02% / °C of span

Output Impedance:

Max. 600 Ω at 24 VDC (50 Ω/V above 12 VDC.)

Current Limitation:

< 26 mA

Isolation voltage:

500 VAC. input/output isolation (1min. test)

Environmental Limits

Operating Temperature:

0 to 55 °C

Operating Humidity:

5 to 95 %RH

Storage Temperature:

0 to 70 °C

Physical Characteristics

Dimension:

W22 x H80 x D85 mm.

Mounting:

DIN or EN Rail

Warranty

Warranty Period:

5 year
Ordering
Ordering Information: Specify Input range
Example SC37/0-10 mV
Packagelist

Package Checklist

1. SC37

Downloads
Datasheet:
application/pdf iconSC37 Specification.pdf
