PT37: Potentiometer Transmitter

- Wide Programmable Input Range

- Isolated Input to Output

- Compact DIN Rail Mount Enclosure

- High Accuracy

- Easy to Install



Specifications

Potentiometer Input

Number of channel:

1 Channel

Input type:

Potentiometer

Input range:

100 Ω to 50 kΩ

Analog Output

Number of channel:

1 Channel

Output type:

Current (2 Wire)

Output range:

4 to 20 mA

Loop powered:

12 to 35 VDC

Accuracy:

< 0.2% of Span

Linearity:

< 0.2% of Span

Ambient drift:

< ± 0.02% / °C of span

Output Impedance:

Max. 600 Ω at 24 VDC (50 Ω/V above 12 VDC.)

Current Limitation:

< 26 mA

Isolation voltage:

500 VAC. input/output isolation (1min. test)

Environmental Limits

Operating Temperature:

0 to 55 °C

Operating Humidity:

5 to 95 %RH

Storage Temperature:

0 to 70 °C

Physical Characteristics

Dimension:

W22 x H80 x D85 mm.

Mounting:

DIN or EN Rail

Warranty

Warranty Period:

5 year
Ordering
Ordering Information:
Example PT37
Packagelist

Package Checklist

1. PT37

Downloads
Datasheet:
application/pdf iconPT37 Specification.pdf
