ES20: Excite D.C. Supply

- 0 to 5 VDC or 0 to 10 Volts Output

- 50 mA Current Output

- 4 Channels Output

- Supply to Load Cells or Strain Gauge etc.

Specifications

Analog Output

Number of Channel:

4 Channels

Output Type:

Voltage

Output Range:

0 to 5 VDC or 0 to 10 VDC

Output Impedance:

50 mA

Power Requirements

Power Supply:

220 VAC

12, 24 VDC (Optional)

Environmental Limits

Operating Temperature:

0 to 55 °C

Operating Humidity:

5 to 95 %RH

Storage Temperature:

0 to 70 °C

Physical Characteristics

Dimension:

W50 x H70 x D130 mm.

Mounting:

DIN Rail

Warranty

Warranty Period:

5 year
Ordering
Ordering Information: Specify Power Supply
Example ES20/220VAC
Packagelist

Package Checklist

1. ES20

Downloads
Datasheet:
application/pdf iconES20 Specification.pdf
